DUP-2490M2610-30SNS

by RF-Duplexer
RFHB04G18GPI Image

RF Solution offer a wide selection of RF Duplexer for global customers. DUP-2490M2610-30SNS is a RF Duplexer in Frequency Range of 2490~2640 MHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 1.4 dB, Ripple Max is 1.0 dB and Return Loss Min is 18 dB. The component has a good working performance and stability, it is ideal for handling a Power Rating of 5 W.

Product Specifications

Product Details

  • Part Number
    DUP-2490M2610-30SNS
  • Description
    2490~2640 MHz RF Duplexer

General Parameters

  • Frequency Range
    2490~2640 MHz
  • Insertion Loss Max
    1.4 dB
  • Ripple Max
    1.0 dB
  • Return Loss Min
    18 dB
  • Power Rating
    5 W
  • Rejection Min
    90 dB
  • Bandwidth
    30 MHz
  • VSWR Max
    /
  • Impedance
    50 Ω
  • Connector Type
    N-F / SMA-F
  • Size
    192*88*40 mm
  • Color
    Black
  • Operating Temperature
    -20~+60 ℃
  • ROHS Compliant
    Yes
