TG6237AS

by Coaxial-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Isolator for global customers. TG6237AS is a Coaxial Isolator in Frequency Range of 2.0~8.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 1.20~1.70 dB and Isolation Min is 13.0~15.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 20 W.

Product Specifications

Product Details

  • Part Number
    TG6237AS
  • Description
    2.0 to 8.0 GHz Coaxial Isolator

General Parameters

  • Frequency Range
    2.0~8.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    1.20~1.70 dB
  • Isolation Min
    13.0~15.0 dB
  • Forward Power
    20 W
  • Reverse Power
    10 W
  • VSWR Max
    1.50~1.60
  • Impedance
    50 Ω
  • Connector Type
    SMA-F
  • Size
    62.0*36.8*19.6 mm
  • Weight
    260 g
  • Operating Temperature
    -10~+60 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
TG6237AS-X/2.0-6.0GHz 2.0-6.0 1.20 15.0 1.50 20 10
TG6237AS-X/2.0-8.0GHz 2.0-8.0 1.70@2.0-2.02GHz/1.50@2.02-8.0GHz 13.0 1.60 20 10
