Coaxial Isolator

There are 64 related products in the Coaxial Isolator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 30 MHz to 31.0 GHz Coaxial Isolator
  • Frequency Range: 30MHz-31.0GHz
  • Impedance: 50 Ω
  • ROHS Compliant: Yes
  • Reverse Power: 2-100 W
  • Forward Power: 10-500 W
  • Description: 40.0 to 50.0 GHz Coaxial Isolator
  • Frequency Range: 40.0~50.0 GHz
  • Bandwidth Max: 12%
  • Insertion Loss Max: 0.80~1.60 dB
  • Isolation Min: 12.0~15.0 dB
  • Forward Power: 10 W
  • Reverse Power: 1 W
  • Description: 22.0 to 33.0 GHz Coaxial Isolator
  • Frequency Range: 26.5~40.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.50~1.70 dB
  • Isolation Min: 12.0~14.0 dB
  • Forward Power: 10 W
  • Reverse Power: 2 W
  • Description: 22.0 to 33.0 GHz Coaxial Isolator
  • Frequency Range: 22.0~33.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.30~1.60 dB
  • Isolation Min: 15.0~16.0 dB
  • Forward Power: 10 W
  • Reverse Power: 2 W
  • Description: 18.0 to 28.0 GHz Coaxial Isolator
  • Frequency Range: 18.0~28.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.70~0.90 dB
  • Isolation Min: 20.0 dB
  • Forward Power: 10 W
  • Reverse Power: 2 W
  • Description: 6.0 to 35.0 GHz Coaxial Isolator
  • Frequency Range: 6.0~35.0 GHz
  • Bandwidth Max: 75%
  • Insertion Loss Max: 0.30~0.60 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 30/60 W
  • Reverse Power: 5 W
  • Description: 4.0 to 8.0 GHz - 300W Coaxial Isolator
  • Frequency Range: 4.0~8.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.30~0.50 dB
  • Isolation Min: 20.0~23.0 dB
  • Forward Power: 300 W
  • Reverse Power: 100 W
  • Description: 4.4 to 7.2 GHz Coaxial Isolator
  • Frequency Range: 4.4~7.2 GHz
  • Bandwidth Max: 25%
  • Insertion Loss Max: 0.30~0.50 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 60 W
  • Reverse Power: 5 W
  • Description: 700 to 2500 MHz Coaxial Isolator
  • Frequency Range: 700~5000 MHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.30~0.50 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 100/150/200 W
  • Reverse Power: 30 W
  • Description: 700 to 2500 MHz Coaxial Isolator
  • Frequency Range: 700~5000 MHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.30~0.50 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 100/150/200 W
  • Reverse Power: 30 W
  • Description: 700 to 2500 MHz Coaxial Isolator
  • Frequency Range: 700~2500 MHz
  • Bandwidth Max: 35%
  • Insertion Loss Max: 0.30~0.50 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 100/200 W
  • Reverse Power: 30 W
  • Description: 700 to 2000 MHz Coaxial Isolator
  • Frequency Range: 700~2000 MHz
  • Bandwidth Max: 40%
  • Insertion Loss Max: 0.25~0.6 dB
  • Isolation Min: 16.0~23.0 dB
  • Forward Power: 100/200 W
  • Reverse Power: 30 W
