BSF-5400M5900A-S

by Band-Stop-Filter
RFHB04G18GPI Image

RF Solution offer a wide selection of Band Stop Filter for global customers. BSF-5400M5900A-S is a Band Stop Filter in Rejection Band of 5400~5900 MHz. It is made of high quality materials under a high standard, the Pass Band of this product is DC~5100MHz / 6200~12000MHz, Insertion Loss Max is 2.0 dB and Rejection Min is 40 dB. The component has a good working performance and stability, it is ideal for handling a Rated Power of 30 W.

Product Specifications

Product Details

  • Part Number
    BSF-5400M5900A-S
  • Description
    5400~5900 MHz Band Stop Filter

General Parameters

  • Rejection Band
    5400~5900 MHz
  • Pass Band
    DC~5100MHz / 6200~12000MHz
  • Insertion Loss Max
    2.0 dB
  • Rejection Min
    40 dB
  • Rated Power
    30 W
  • VSWR Max
    2.00
  • Impedance
    50 Ω
  • Connector Type
    SMA-F
  • Size
    70*25*15 mm
  • Surface Finishing
    Black Painting
  • Operating Temperature
    Ordinary temperature
  • Storage Temperature
    -55~+85 °C
  • ROHS Compliant
    Yes
