RFTXX-20MA0919-10

by Microstrip-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Attenuator for global customers. RFTXX-20MA0919-10 is a Microstrip Attenuator in Frequency Range of DC~10.0 GHz. It is made of high quality materials under a high standard, the Attenuation Value of this product is ①1-10 dB ②11-20 dB ③21-30 dB ④ 40/50 dB, Attenuation Tolerance is ①±0.5 dB ②±0.6 dB ③± 1.0 dB ④±1.2 dB and VSWR Max is 1.25 type 1.3. The component has a good working performance and stability, it is ideal for handling a Rated Power of 20 W.

Product Specifications

Product Details

  • Part Number
    RFTXX-20MA0919-10
  • Description
    DC~10.0 GHz Microstrip Attenuator

General Parameters

  • Frequency Range
    DC~10.0 GHz
  • Attenuation Value
    ①1-10 dB ②11-20 dB ③21-30 dB ④ 40/50 dB
  • Attenuation Tolerance
    ①±0.5 dB ②±0.6 dB ③± 1.0 dB ④±1.2 dB
  • VSWR Max
    1.25 type 1.3
  • Rated Power
    20 W
  • Impedance
    50 Ω
  • Size
    19.0*9.0*0.5 mm
  • Temperature Coefficient Max
    150 ppm/℃
  • Substrate Material
    BeO
  • Resistance Process
    Thick Film
  • Operating Temperature
    -55~+150 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
