Microstrip Attenuator

There are 12 related products in the Microstrip Attenuator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: DC~4.0 GHz Microstrip Attenuator
  • Frequency Range: DC~4.0 GHz
  • Attenuation Value: ①3/6/10 dB ②15/20 dB ③30 dB
  • Attenuation Tolerance: ①±0.6 dB ②±0.8 dB ③± 1.0 dB
  • VSWR Max: 1.25 type 1.30
  • Rated Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~8.0 GHz Microstrip Attenuator
  • Frequency Range: DC~8.0 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB ④40 dB
  • Attenuation Tolerance: ①±0.6 dB ②±0.8 dB ③± 1.0 dB ④±1.2 dB
  • VSWR Max: 1.25 type 1.25
  • Rated Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~18.0 GHz Microstrip Attenuator
  • Frequency Range: DC~18.0 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB
  • Attenuation Tolerance: ①±0.5 dB ②±0.6 dB ③± 1.0 dB
  • VSWR Max: 1.25 type 1.3
  • Rated Power: 30 W
  • Impedance: 50 Ω
  • Description: DC~6.0 GHz Microstrip Attenuator
  • Frequency Range: DC~6.0 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB ④40/50/60 dB
  • Attenuation Tolerance: ①±0.6 dB ②±0.8 dB ③± 1.0 dB ④±1.2 dB
  • VSWR Max: 1.25 type 1.25
  • Rated Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~10.0 GHz Microstrip Attenuator
  • Frequency Range: DC~10.0 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB ④ 40/50 dB
  • Attenuation Tolerance: ①±0.5 dB ②±0.6 dB ③± 1.0 dB ④±1.2 dB
  • VSWR Max: 1.25 type 1.3
  • Rated Power: 20 W
  • Impedance: 50 Ω
  • Description: DC~18.0 GHz Microstrip Attenuator
  • Frequency Range: DC~18.0 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB
  • Attenuation Tolerance: ①±0.5 dB ②±0.6 dB ③± 1.0 dB
  • VSWR Max: 1.25 type 1.3
  • Rated Power: 10 W
  • Impedance: 50 Ω
  • Description: DC~12.4 GHz Microstrip Attenuator
  • Frequency Range: DC~12.4 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB
  • Attenuation Tolerance: ①±0.6 dB ②±0.7 dB ③± 1.0 dB
  • VSWR Max: 1.25 type 1.3
  • Rated Power: 10 W
  • Impedance: 50 Ω
  • Description: DC~12.4 GHz Microstrip Attenuator
  • Frequency Range: DC~12.4 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB
  • Attenuation Tolerance: ①±0.6 dB ②±0.7 dB ③± 1.0 dB
  • VSWR Max: 1.25 type 1.3
  • Rated Power: 5 W
  • Impedance: 50 Ω
  • Description: DC~18.0 GHz Microstrip Attenuator
  • Frequency Range: DC~18.0 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③21-30 dB
  • Attenuation Tolerance: ①±0.7 dB ②±0.8 dB ③± 1.0 dB
  • VSWR Max: 1.25 type 1.3
  • Rated Power: 5 W
  • Impedance: 50 Ω
  • Description: DC~12.4 GHz Microstrip Attenuator
  • Frequency Range: DC~12.4 GHz
  • Attenuation Value: ①1-10 dB ②11-20 dB ③30 dB
  • Attenuation Tolerance: ①±0.5 dB ②±1.0 dB ③±1.0 dB
  • VSWR Max: 1.20 @10GHz, 1.25@12.4GHz
  • Rated Power: 2 W
  • Impedance: 50 Ω
  • Description: DC~18.0 GHz Microstrip Attenuator
  • Frequency Range: DC~18.0 GHz
  • Attenuation Value: 15/20/25/30 dB
  • Attenuation Tolerance: ±1.0 dB
  • VSWR Max: 1.30
  • Rated Power: 2 W
  • Impedance: 50 Ω
  • Description: DC~18.0 GHz Microstrip Attenuator
  • Frequency Range: DC~18.0 GHz
  • Attenuation Value: 1~10 dB
  • Attenuation Tolerance: ±0.5 dB
  • VSWR Max: 1.30
  • Rated Power: 2 W
  • Impedance: 50 Ω
