RFTXXA-02TA5432-18

by Microstrip-Attenuator-with-Sleeve
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Attenuator with Sleeve for global customers. RFTXXA-02TA5432-18 is a Microstrip Attenuator with Sleeve in Frequency Range of DC~18.0GHz. It is made of high quality materials under a high standard, the Attenuation Value of this product is 01-10 dB , Attenuation Tolerance is ±0.5 dB and VSWR Max is 1.30. The component has a good working performance and stability, it is ideal for handling a Power of 2 W.

Product Specifications

Product Details

  • Part Number
    RFTXXA-02TA5432-18
  • Description
    DC~18.0 GHz Microstrip Attenuator With Sleeve

General Parameters

  • Frequency Range
    DC~18.0GHz
  • Attenuation Value
    01-10 dB
  • Attenuation Tolerance
    ±0.5 dB
  • VSWR Max
    1.30
  • Power
    2 W
  • Impedance
    50 Ω
  • Size
    Φ5.4*3.2 mm
  • Temperature Coefficient Max
    150 ppm/℃
  • Substrate Material
    Al2O3
  • Sleeve Material
    Copper (silver plated)
  • Resistance Process
    Thick Film
  • Operating Temperature
    -55 ~+125°C
  • ROHS Compliant
    Yes
