SMTG-D20

by Surface-Mount-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Surface Mount Isolator for global customers. SMTG-D20 is a Surface Mount Isolator in Frequency Range of 700~3000 MHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 20%, Insertion Loss Max is 0.30~0.60 dB and Isolation Min is 17.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 60/100 W.

Product Specifications

Product Details

  • Part Number
    SMTG-D20
  • Description
    700 to 3000 MHz Surface Mount Isolator

General Parameters

  • Frequency Range
    700~3000 MHz
  • Bandwidth Max
    20%
  • Insertion Loss Max
    0.30~0.60 dB
  • Isolation Min
    17.0~23.0 dB
  • Forward Power
    60/100 W
  • Reverse Power
    10 W
  • VSWR Max
    1.20~1.58
  • Impedance
    50 Ω
  • Connector Type
    SMT
  • Size
    Φ20.0*8.0 mm
  • Weight
    25 g
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (MHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
SMTG-D20-X/758-803MHz 758-803 0.40 20.0 1.25 60 10
SMTG-D20-X/900-930MHz 900-930 0.40 23.0 1.20 100 10
SMTG-D20-X/925-960MHz 925-960 0.40 20.0 1.25 100 10
SMTG-D20-X/1017-1103MHz 1017-1103 0.40 20.0 1.25 100 10
SMTG-D20-X/1200-1400MHz 1200-1400 0.40 20.0 1.25 100 10
SMTG-D20-X/1400-1500MHz 1400-1500 0.30 23.0 1.20 100 10
SMTG-D20-X/1600-2000MHz 1600-2000 0.60 17.0 1.35 100 10
SMTG-D20-X/1830-2650MHz 1830-2650 0.60 13.0 1.58 100 10
SMTG-D20-X/2110-2155MHz 2110-2155 0.30 23.0 1.20 60 10
SMTG-D20-X/2400-2500MHz 2400-2500 0.30 23.0 1.20 100 10
SMTG-D20-X/2500-2630MHz 2500-2630 0.40 20.0 1.25 60 10
