RF Solution offer a wide selection of Surface Mount Isolator for global customers. SMTG-D15 is a Surface Mount Isolator in Frequency Range of 1.0~5.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 15%, Insertion Loss Max is 0.25~0.50 dB and Isolation Min is 20.0~25.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 60 W.
| Part Number | Frequency Range (MHz) | Insertion Loss Max (dB) | Isolation Min (dB) | VSWR Max | Forward Power (W) | Reverse Power (W) | Choose |
|---|---|---|---|---|---|---|---|
| SMTG-D15-X/1000-1080MHz | 1000-1080 | 0.50 | 20.0 | 1.25 | 60 | 10 | |
| SMTG-D15-X/1240-1260MHz | 1240-1260 | 0.40 | 20.0 | 1.25 | 60 | 10 | |
| SMTG-D15-X/1350-1410MHz | 1350-1410 | 0.40 | 20.0 | 1.25 | 60 | 10 | |
| SMTG-D15-X/1800-1870MHz | 1800-1870 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/2400-2600MHz | 2400-2600 | 0.40 | 20.0 | 1.25 | 60 | 10 | |
| SMTG-D15-X/3100-3400MHz | 3100-3400 | 0.40 | 20.0 | 1.25 | 60 | 10 | |
| SMTG-D15-X/3240-3340MHz | 3240-3340 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/3620-3630MHz | 3620-3630 | 0.25 | 25.0 | 1.15 | 60 | 10 | |
| SMTG-D15-X/3650-3750MHz | 3650-3750 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/3700-3800MHz | 3700-3800 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/3800-4100MHz | 3800-4100 | 0.40 | 20.0 | 1.25 | 60 | 10 | |
| SMTG-D15-X/4000-4100MHz | 4000-4100 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/4200-4400MHz | 4200-4400 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/4500-4700MHz | 4500-4700 | 0.30 | 23.0 | 1.20 | 60 | 10 | |
| SMTG-D15-X/4800-5000MHz | 4800-5000 | 0.30 | 23.0 | 1.20 | 60 | 10 |
