MG1517-10

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG1517-10 is a Microstrip Isolator in Frequency Range of 2.0~6.0 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 1.30~1.50 dB, Isolation Min is 10.0~11.0 dB and VSWR Max is 1.70~1.80. The component has a good working performance and stability, it is ideal for handling a Forward Power of 50 W.

Product Specifications

Product Details

  • Part Number
    MG1517-10
  • Description
    2.0 to 6.0 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    2.0~6.0 GHz
  • Insertion Loss Max
    1.30~1.50 dB
  • Isolation Min
    10.0~11.0 dB
  • VSWR Max
    1.70~1.80
  • Forward Power
    50 W
  • Reverse Power
    2 W
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    15.0*17.0*4.0 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
MG1517-10-X/2.0-6.0GHz 2.0-6.0 1.30/1.50 11.0/10.0 1.70/1.80 50 2
