MG3505-06

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG3505-06 is a Microstrip Isolator in Frequency Range of 26.0~40.0 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 1.20 dB, Isolation Min is 11.0 dB and VSWR Max is 1.60. The component has a good working performance and stability, it is ideal for handling a Forward Power of 4 W.

Product Specifications

Product Details

  • Part Number
    MG3505-06
  • Description
    26.0 to 40.0 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    26.0~40.0 GHz
  • Insertion Loss Max
    1.20 dB
  • Isolation Min
    11.0 dB
  • VSWR Max
    1.60
  • Forward Power
    4 W
  • Reverse Power
    /
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    3.5*5.0*3.2 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Choose
MG3505-06-X/26.0-40.0GHz 26.0-40.0 1.20 11.0 1.60 4
