BG4457-WR75

by Waveguide-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Waveguide Isolator for global customers. BG4457-WR75 is a Waveguide Isolator in Frequency Range of 10.0~15.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 500M, Insertion Loss Max is 0.25~0.40 dB and Isolation Min is 20.0~25.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of /.

Product Specifications

Product Details

  • Part Number
    BG4457-WR75
  • Description
    10.0 to 15.0 GHz Waveguide Isolator

General Parameters

  • Frequency Range
    10.0~15.0 GHz
  • Bandwidth Max
    500M
  • Insertion Loss Max
    0.25~0.40 dB
  • Isolation Min
    20.0~25.0 dB
  • Forward Power
    /
  • Reverse Power
    /
  • VSWR Max
    1.15~1.25
  • Impedance
    50 Ω
  • Connector Type
    WR75
  • Size
    57.1*44.5*38.1 mm
  • Weight
    /
  • Operating Temperature
    -40~+80 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Bandwidth Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Choose
BG4457-WR75/10.0-15.0GHz 10.0-15.0 500M 0.30 23.0 1.20
BG4457-WR75/10.7-12.8GHz 10.7-12.8 100% 0.25 25.0 1.15
BG4457-WR75/10.0-13.0GHz 10.0-13.0 100% 0.40 20.0 1.25
