PD04-F5235-S-6-40GHz

by 4-Ways-Power-Divider
RFHB04G18GPI Image

RF Solution offer a wide selection of 4 Ways Power Divider for global customers. PD04-F5235-S-6-40GHz is a 4 Ways Power Divider in Frequency Range of 6.0~40.0 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 1.8 dB, Isolation Min is 16 dB and Amplitude Unbalance is ±0.4 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 10 W.

Product Specifications

Product Details

  • Part Number
    PD04-F5235-S-6-40GHz
  • Description
    6.0~40.0 GHz 4 Ways Power Divider

General Parameters

  • Frequency Range
    6.0~40.0 GHz
  • Insertion Loss Max
    1.8 dB
  • Isolation Min
    16 dB
  • Amplitude Unbalance
    ±0.4 dB
  • Forward Power
    10 W
  • Reverse Power
    1 W
  • VSWR Input Max
    1.80
  • VSWR Output Max
    1.80
  • Phase Unbalance
    ±8°
  • Impedance
    50 Ω
  • Connector Type
    SMA-F
  • Size
    52*35*10 mm
  • Weight
    /
  • Surface Finishing
    Grey Painting
  • Operating Temperature
    -45~+85 °C
  • ROHS Compliant
    Yes
