A5 RF Variable Attenuator

by Variable-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Variable Attenuator for global customers. A5 RF Variable Attenuator is a Variable Attenuator in Frequency Range of DC~26.5 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 1.8 dB, Attenuation Value & Step is ①0-9dB（1dB step）②0-99 dB（1 dB step） and Attenuation Tolerance Min is ±0.6 dB. The component has a good working performance and stability, it is ideal for handling a Average Power of 2/10/25 W.

Product Specifications

Product Details

  • Part Number
    A5 RF Variable Attenuator
  • Description
    DC~26.5 GHz RF Variable Attenuator

General Parameters

  • Frequency Range
    DC~26.5 GHz
  • Insertion Loss Max
    1.8 dB
  • Attenuation Value & Step
    ①0-9dB（1dB step）②0-99 dB（1 dB step）
  • Attenuation Tolerance Min
    ±0.6 dB
  • Average Power
    2/10/25 W
  • Peak Power
    200 W (5uS Pulse width, 2% Duty cycle)
  • VSWR Max
    1.80
  • Impedance
    50 Ω
  • Connector Type
    SMA（FF,DC-18GHz);3.5（FF-26.5GHz）
  • Operating Temperature
    0～54 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Attenuation & Step Insertion Loss Max (dB) VSWR Max Attenuation Tolerance (dB) Choose
RKTX2-1-9-8.0-A5 DC-8.0 0-9dB 1dB Step 0.80 1.40 ±0.6
RKTX2-1-9-12.4-A5 DC-12.4 0-9dB 1dB Step 1.00 1.50 ±0.8
RKTX2-1-9-18.0-A5 DC-18.0 0-9dB 1dB Step 1.20 1.60 ±1.0
RKTX2-1-9-26.5-A5 DC-26.5 0-9dB 1dB Step 1.80 1.75 ±1.0
RKTX2-1-90-8.0-A5 DC-8.0 0-90dB 10dB Step 1.00 1.40 ±1.5(10-60dB) ±2.5 or 3.5%(70-90dB)
RKTX2-1-90-12.4-A5 DC-12.4 0-90dB 10dB Step 1.20 1.50 ±1.5(10-60dB) ±2.5 or 3.5%(70-90dB)
RKTX2-1-90-18.0-A5 DC-18.0 0-90dB 10dB Step 1.50 1.60 ±1.5(10-60dB) ±2.5 or 3.5%(70-90dB)
RKTX10-1-9-8.0-A5 DC-8.0 0-9dB 1dB Step 0.80 1.40 ±0.6
RKTX10-1-9-12.4-A5 DC-12.4 0-9dB 1dB Step 1.00 1.50 ±0.8
RKTX10-1-9-18.0-A5 DC-18.0 0-9dB 1dB Step 1.20 1.60 ±1.0
RKTX10-1-9-8.0-A5 DC-26.5 0-9dB 1dB Step 1.80 1.75 ±1.0
RKTX10-1-90-8.0-A5 DC-8.0 0-90dB 10dB Step 1.00 1.40 ±1.5(10-60dB) ±2.5 or 3.5%(70-90dB)
RKTX10-1-90-12.4-A5 DC-12.4 0-90dB 10dB Step 1.20 1.50 ±1.5(10-60dB) ±2.5 or 3.5%(70-90dB)
RKTX10-1-90-18.0-A5 DC-18.0 0-90dB 10dB Step 1.50 1.60 ±1.5(10-60dB) ±2.5 or 3.5%(70-90dB)
RKTX10-1-60-26.5-A5 DC-26.5 0-60dB 10dB Step 1.80 1.75 ±1.5dB or 4%
RKTX25-1-70-18.0-A5 DC-18.0 0-70dB 10dB Step 1.00 1.65 ±1.5dB or 4%
RKTX25-1-60-26.5-A5 DC-26.5 0-60dB 10dB Step 1.80 1.80 ±1.5dB or 4%
