RF Solution offer a wide selection of Coaxial Isolator for global customers. TG1017CG is a Coaxial Isolator in Frequency Range of 19.0~31.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 38%, Insertion Loss Max is 0.70~1.20 dB and Isolation Min is 20.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 5/10 W.
| Part Number | Frequency Range (GHz) | Insertion Loss Max (dB) | Isolation Min (dB) | VSWR Max | Forward Power (W) | Reverse Power (W) | Choose |
|---|---|---|---|---|---|---|---|
| TG1017CG-X/17.0-20.5GHz | 17.0-20.5 | 0.70 | 20.0 | 1.30 | 10 | 2 | |
| TG1017CG-X/18.0-26.5GHz | 18.0-26.5 | 0.90 | 20.0 | 1.30 | 10 | 2 | |
| TG1017CG-X/22.0-28.0GHz | 22.0-28.0 | 1.20 | 20.0 | 1.30 | 5 | 1 | |
| TG1017CG-X/25.0-28.0GHz | 25.0-28.0 | 1.00 | 20.0 | 1.30 | 5 | 1 | |
| TG1017CG-X/27.0-31.0GHz | 27.0-31.0 | 1.00 | 20.0 | 1.30 | 5 | 1 |
