RF Solution offer a wide selection of Microstrip Isolator for global customers. MG1214-10 is a Microstrip Isolator in Frequency Range of 2.7~8.0 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 0.40~0.80 dB, Isolation Min is 14.0~20.0 dB and VSWR Max is 1.00~1.50. The component has a good working performance and stability, it is ideal for handling a Forward Power of 50 W.
| Part Number | Frequency Range (GHz) | Insertion Loss Max (dB) | Isolation Min (dB) | VSWR Max | Forward Power (W) | Reverse Power (W) | Choose |
|---|---|---|---|---|---|---|---|
| MG1214-10-X/2.7-3.5GHz | 2.7-3.5 | 0.40 | 20.0 | 1.20 | 50 | 2 | |
| MG1214-10-X/3.5-4.5GHz | 3.5-4.5 | 0.40 | 20.0 | 1.00 | 50 | 2 | |
| MG1214-10-X/4.0-5.0GHz | 4.0-5.0 | 0.40 | 20.0 | 1.20 | 50 | 2 | |
| MG1214-10-X/4.0-8.0GHz | 4.0-8.0 | 0.70/0.80 | 16.0/14.0 | 1.40/1.50 | 50 | 2 | |
| MG1214-10X/4.4-5.5GHz | 4.4-5.5 | 0.40 | 20.0 | 1.20 | 50 | 2 |
