MG0607-07

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG0607-07 is a Microstrip Isolator in Frequency Range of 8.0~8.4 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 0.50 dB, Isolation Min is 20.0 dB and VSWR Max is 1.25. The component has a good working performance and stability, it is ideal for handling a Forward Power of 5 W.

Product Specifications

Product Details

  • Part Number
    MG0607-07
  • Description
    8.0 to 8.4 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    8.0~8.4 GHz
  • Insertion Loss Max
    0.50 dB
  • Isolation Min
    20.0 dB
  • VSWR Max
    1.25
  • Forward Power
    5 W
  • Reverse Power
    2 W
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    6.0*7.0*3.5 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
MG0607-07-X/8.0-8.4GHz 8.0-8.4 0.50 20.0 1.25 5 2
