MG3504-07

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG3504-07 is a Microstrip Isolator in Frequency Range of 18.5~25.0 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 0.50~0.60 dB, Isolation Min is 24.0~41.5 dB and VSWR Max is 1.30~1.45. The component has a good working performance and stability, it is ideal for handling a Forward Power of 10 W.

Product Specifications

Product Details

  • Part Number
    MG3504-07
  • Description
    24.0 to 41.5 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    18.5~25.0 GHz
  • Insertion Loss Max
    0.50~0.60 dB
  • Isolation Min
    24.0~41.5 dB
  • VSWR Max
    1.30~1.45
  • Forward Power
    10 W
  • Reverse Power
    1 W
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    3.5*4.0*3.0 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
MG3504-07-X/24.0-27.5GHz 24.0-27.5 0.60 18.0 1.30 10 1
MG3504-07-X/27.0-29.5GHz 27.0-29.5 0.70 20.0 1.30 10 1
MG3504-07-X/29.0-31.5GHz 29.0-31.5 0.70 18.0 1.30 10 1
MG3504-07-X/26.0-28.5GHz 26.0-28.5 0.70 20.0 1.30 10 1
MG3504-07-X/27.0-31.0GHz 27.0-31.0 0.70 18.0 1.35 10 1
MG3504-07-X/28.0-33.0GHz 28.0-33.0 0.70 18.0 1.35 10 1
MG3504-07-X/33.0-37.0GHz 33.0-37.0 0.80 18.0 1.35 10 1
MG3504-07-X/32.0-36.0GHz 32.0-36.0 0.80 18.0 1.40 10 1
MG3504-07-X/35.0-38.0GHz 35.0-38.0 0.80 18.0 1.40 10 1
MG3504-07-X/32.0-38.0GHz 32.0-38.0 1.00 15.0 1.45 10 1
MG3504-07-X/37.5-41.5GHz 37.5-41.5 1.00 18.0 1.40 10 1
