BG2552-WR75

by Waveguide-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Waveguide Isolator for global customers. BG2552-WR75 is a Waveguide Isolator in Frequency Range of 10.0~15.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 5%/10%, Insertion Loss Max is 0.25~0.30 dB and Isolation Min is 23.0~25.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of /.

Product Specifications

Product Details

  • Part Number
    BG2552-WR75
  • Description
    10.0 to 15.0 GHz Waveguide Isolator

General Parameters

  • Frequency Range
    10.0~15.0 GHz
  • Bandwidth Max
    5%/10%
  • Insertion Loss Max
    0.25~0.30 dB
  • Isolation Min
    23.0~25.0 dB
  • Forward Power
    /
  • Reverse Power
    /
  • VSWR Max
    1.15~1.20
  • Impedance
    50 Ω
  • Connector Type
    WR75
  • Size
    52*25*38 mm
  • Weight
    /
  • Operating Temperature
    -40~+80 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Bandwidth Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Choose
BG2552-WR75/10.0-15.0GHz 10.0-15.0 5%/10% 0.25/0.30 23.0/25.0 1.15/1.20
