WH3234B

by Drop-in-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Circulator for global customers. WH3234B is a Drop in Circulator in Frequency Range of 2.0~4.20 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.50~0.60 dB and Isolation Min is 18.0~19.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 150 W.

Product Specifications

Product Details

  • Part Number
    WH3234B
  • Description
    2.0 to 4.2 GHz Drop in Circulator

General Parameters

  • Frequency Range
    2.0~4.20 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    0.50~0.60 dB
  • Isolation Min
    18.0~19.0 dB
  • Power
    150 W
  • VSWR Max
    1.25~1.35
  • Impedance
    50 Ω
  • Connector Type
    /
  • Size
    32.0*34.0*21.0 mm
  • Weight
    100 g
  • Operating Temperature
    -10~+60 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR （Max） Power （W） Choose
WH3234B-X/2.0-2.6GHz 2.0-2.6 0.50 18.0 1.30 150
WH3234B-X/2.0-2.9GHz 2.0-2.9 0.50 18.0 1.30 150
WH3234B-X/2.0-3.0GHz 2.0-3.0 0.50 18.0 1.30 150
WH3234B-X/2.0-3.5GHz 2.0-3.5 0.60 18.0 1.30 150
WH3234B-X/2.0-4.0GHz 2.0-4.0 0.60 18.0 1.30 150
WH3234B-X/2.35-4.0GHz 2.35-4.0 0.50 18.0 1.30 150
WH3234B-X/2.4-4.0GHz 2.4-4.0 0.60 18.0 1.30 150
WH3234B-X/2.5-3.8GHz 2.5-3.8 0.50 18.0 1.35 150
WH3234B-X/2.5-3.5GHz 2.5-3.5 0.60 19.0 1.25 150
WH3234B-X/2.5-4.0GHz 2.5-4.0 0.60 18.0 1.30 150
