WH1220D

by Drop-in-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Circulator for global customers. WH1220D is a Drop in Circulator in Frequency Range of 5.5~7.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 60%, Insertion Loss Max is 0.30~0.50 dB and Isolation Min is 18.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 30 W.

Product Specifications

Product Details

  • Part Number
    WH1220D
  • Description
    5.5 to 7.0 GHz Drop in Circulator

General Parameters

  • Frequency Range
    5.5~7.0 GHz
  • Bandwidth Max
    60%
  • Insertion Loss Max
    0.30~0.50 dB
  • Isolation Min
    18.0~23.0 dB
  • Power
    30 W
  • VSWR Max
    1.20~1.30
  • Impedance
    50 Ω
  • Connector Type
    /
  • Size
    12.0*20.0*9.5 mm
  • Weight
    15 g
  • Operating Temperature
    -30~+70 ℃/-40~+85 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR （Max） Power （W） Choose
WH1220D-X/5.5-5.7GHz 5.5-5.7 0.40 20.0 1.20 30
WH1220D-X/5.6-6.0GHz 5.6-6.0 0.40 19.0 1.25 30
WH1220D-X/5.7-5.9GHz 5.7-5.9 0.30 23.0 1.20 30
WH1220D-X/5.7-6.5GHz 5.7-6.5 0.50 18.0 1.30 30
WH1220D-X/5.78-6.0GHz 5.78-6.0 0.40 20.0 1.20 30
WH1220D-X/5.8-6.5GHz 5.8-6.5 0.50 18.0 1.30 30
WH1220D-X/5.85-6.73GHz 5.85-6.73 0.50 18.0 1.30 30
WH1220D-X/6.0-7.0GHz 6.0-7.0 0.50 18.0 1.30 30
WH1220D-X/6.35-6.55GHz 6.35-6.55 0.30 23.0 1.20 30
WH1220D-X/6.5-7.0GHz 6.5-7.0 0.40 20.0 1.25 30
WH1220D-X/6.57-6.87GHz 6.57-6.87 0.30 20.0 1.25 30
WH1220D-X/6.7-7.0GHz 6.7-7.0 0.30 20.0 1.25 30
