WH0915D

by Drop-in-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Circulator for global customers. WH0915D is a Drop in Circulator in Frequency Range of 6.0~10.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 50%, Insertion Loss Max is 0.30~0.60 dB and Isolation Min is 18.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 30 W.

Product Specifications

Product Details

  • Part Number
    WH0915D
  • Description
    6.0 to 10.0 GHz Drop in Circulator

General Parameters

  • Frequency Range
    6.0~10.0 GHz
  • Bandwidth Max
    50%
  • Insertion Loss Max
    0.30~0.60 dB
  • Isolation Min
    18.0~23.0 dB
  • Power
    30 W
  • VSWR Max
    1.20~1.30
  • Impedance
    50 Ω
  • Connector Type
    /
  • Size
    8.9*15.0*7.8 mm
  • Weight
    5 g
  • Operating Temperature
    -30~+70 ℃/-40~+85 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR （Max） Power （W） Choose
WH0915D-X/6.0-8.0GHz 6.0-8.0 0.60 18.0 1.30 30
WH0915D-X/7.0-8.5GHz 7.0-8.5 0.30 20.0 1.25 30
WH0915D-X/7.0-9.0GHz 7.0-9.0 0.30 18.0 1.30 30
WH0915D-X/7.5-8.0GHz 7.5-8.0 1.30 11.0 1.90 30
WH0915D-X/7.7-8.1GHz 7.7-8.1 0.30 23.0 1.20 30
WH0915D-X/7.7-8.8GHz 7.7-8.8 0.40 20.0 1.25 30
WH0915D-X/7.1-9.5GHz 7.1-9.5 0.60 18.0 1.30 30
WH0915D-X/7.9-9.5GHz 7.9-8.4 0.30 23.0 1.20 30
WH0915D-X/8.0-9.0GHz 8.0-9.0 0.40 20.0 1.25 30
WH0915D-X/8.0-10.0GHz 8.0-10.0 0.40 20.0 1.25 30
WH0915D-X/8.3-8.5GHz 8.3-8.5 0.30 23.0 1.20 30
WH0915D-X/8.5-9.5GHz 8.5-9.5 0.35 20.0 1.20 30
WH0915D-X/8.9-9.6GHz 8.9-9.6 0.40 20.0 1.25 30
WH0915D-X/9.0-9.8GHz 9.0-9.8 0.35 23.0 1.20 30
WH0915D-X/9.0-10.0GHz 9.0-10.0 0.40 20.0 1.25 30
WH0915D-X/9.2-9.5GHz 9.2-9.5 0.30 23.0 1.20 30
WH0915D-X/9.3-10.0GHz 9.3-10.0 0.35 23.0 1.20 30
WH0915D-X/9.4-9.5GHz 9.4-9.5 0.30 23.0 1.20 30
