BH4853-WR90

by Waveguide-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Waveguide Circulator for global customers. BH4853-WR90 is a Waveguide Circulator in Frequency Range of 8.0~12.4 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 20%, Insertion Loss Max is 0.25 dB and Isolation Min is 23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of /.

Product Specifications

Product Details

  • Part Number
    BH4853-WR90
  • Description
    8.0 to 12.4 GHz Waveguide Circulator

General Parameters

  • Frequency Range
    8.0~12.4 GHz
  • Bandwidth Max
    20%
  • Insertion Loss Max
    0.25 dB
  • Isolation Min
    23.0 dB
  • Forward Power
    /
  • VSWR Max
    1.15
  • Impedance
    50 Ω
  • Connector Type
    WR90
  • Size
    53*48*42 mm
  • Weight
    /
  • Operating Temperature
    -40~+80 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
