Waveguide Circulator

There are 14 related products in the Waveguide Circulator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 26.5 to 40.0 GHz Waveguide Circulator
  • Frequency Range: 26.5~40.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.35 dB
  • Isolation Min: 15.0 dB
  • Forward Power: /
  • VSWR Max: 1.20
  • Description: 14.5 to 22.0 GHz Waveguide Circulator
  • Forward Power: /
  • VSWR Max: 1.12~1.15
  • Impedance: 50 Ω
  • Connector Type : WR51
  • Size: 48*38*33.3 mm
  • Weight: /
  • Description: 14.5 to 22.0 GHz Waveguide Circulator
  • Frequency Range: 14.5~22.0 GHz
  • Bandwidth Max: 5/10%
  • Insertion Loss Max: 0.30 dB
  • Isolation Min: 23.0~25.0 dB
  • Forward Power: /
  • VSWR Max: 1.12~1.15
  • Description: 12.0 to 18.0 GHz Waveguide Circulator
  • Frequency Range: 12.0~18.0 GHz
  • Bandwidth Max: 10/100%
  • Insertion Loss Max: 0.30~0.40 dB
  • Isolation Min: 20.0~23.0 dB
  • Forward Power: /
  • VSWR Max: 1.15~1.25
  • Description: 10.0 to 15.0 GHz Waveguide Circulator
  • Frequency Range: 10.0~15.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.30 dB
  • Isolation Min: 18.0 dB
  • Forward Power: /
  • VSWR Max: 1.25
  • Description: 10.0 to 15.0 GHz Waveguide Circulator
  • Frequency Range: 10.0~15.0 GHz
  • Bandwidth Max: 5/10/100%
  • Insertion Loss Max: 0.25~0.30 dB
  • Isolation Min: 23.0~25.0 dB
  • Forward Power: /
  • VSWR Max: 1.12~1.20
  • Description: 10.0 to 15.0 GHz Waveguide Circulator
  • Frequency Range: 10.0~15.0 GHz
  • Bandwidth Max: 10/20%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 23.0~25.0 dB
  • Forward Power: /
  • VSWR Max: 1.12~1.15
  • Description: 9.2 to 9.55 GHz Waveguide Circulator
  • Frequency Range: 9.0~9.55 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.35 dB
  • Isolation Min: 20.0 dB
  • Forward Power: /
  • VSWR Max: 1.25
  • Description: 8.0 to 12.4 GHz Waveguide Circulator
  • Frequency Range: 8.0~12.4 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 23.0 dB
  • Forward Power: /
  • VSWR Max: 1.15
  • Description: 8.0 to 12.4 GHz Waveguide Circulator
  • Frequency Range: 8.0~12.4 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 23.0 dB
  • Forward Power: /
  • VSWR Max: 1.15
  • Description: 7.0 to 10.0 GHz Waveguide Circulator
  • Storage Temperature: /
  • ROHS Compliant: Yes
  • Frequency Range: 7.0~10.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 25.0 dB
  • Description: 5.4 to 8.0 GHz Waveguide Circulator
  • Frequency Range: 5.4~8.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 25.0 dB
  • Forward Power: /
  • VSWR Max: 1.12
