RFTXX-1500FA3049-N-1

by Coaxial-Fixed-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Fixed Attenuator for global customers. RFTXX-1500FA3049-N-1 is a Coaxial Fixed Attenuator in Frequency Range of DC~1.0 GHz. It is made of high quality materials under a high standard, the VSWR Max of this product is 1.35, Attenuation Value is ①20 dB ②30, 40, 50, 60 dB and Attenuation Tolerance is ①±1.3 dB ②±1.8 dB. The component has a good working performance and stability, it is ideal for handling a Power of 1500 W.

Product Specifications

Product Details

  • Part Number
    RFTXX-1500FA3049-N-1
  • Description
    DC~1.0 GHz Coaxial Fixed Attenuator

General Parameters

  • Frequency Range
    DC~1.0 GHz
  • VSWR Max
    1.35
  • Attenuation Value
    ①20 dB ②30, 40, 50, 60 dB
  • Attenuation Tolerance
    ①±1.3 dB ②±1.8 dB
  • Power
    1500 W
  • Impedance
    50 Ω
  • Connector Type
    N-J(M)/ N-K(F)
  • Size
    110*380*534 mm
  • Weight
    17500 g
  • Operating Temperature
    -55~+125 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
