RF Solution

Coaxial Fixed Attenuator

There are 152 related products in the Coaxial Fixed Attenuator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: DC~6.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.25
  • Attenuation Value: ①10 dB ②11-20 dB ③30, 40dB ④50, 60 dB
  • Attenuation Tolerance: ①±1.0 dB ②±1.2 dB ③±1.2 dB ④±1.5 dB
  • Power: 300 W
  • Impedance: 50 Ω
  • Description: DC~6.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.20
  • Attenuation Value: ①1-10 dB②11-20 dB③21-30,40 dB
  • Attenuation Tolerance: ①±0.6 dB②±0.8 dB③±1.0 dB
  • Power: 10 W
  • Impedance: 50 Ω
  • Description: DC~4.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~4.0 GHz
  • VSWR Max: 1.20
  • Attenuation Value: ①1-10 dB②12,13,15,20 dB③25,30,40 dB
  • Attenuation Tolerance: ①±0.6 dB②±0.8 dB③±1.0 dB
  • Power: 5 W
  • Impedance: 50 Ω
  • Description: DC~6.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.30
  • Attenuation Value: ①01-10 dB ②11-20 dB ③21-30 dB ④31-40 dB
  • Attenuation Tolerance:  ①±0.6 dB ②±0.8 dB ③±1.0 dB ④±1.2 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~4.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.20
  • Attenuation Value: ①01-10 dB ②11-20 dB ③21-40 dB ④50, 60 dB
  • Attenuation Tolerance:  ①±0.6 dB ②±0.8 dB ③±1.0 dB ④±1.2 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~6.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.20
  • Attenuation Value: ①01-10 dB ②11-20 dB ③21-40 dB ④50, 60 dB
  • Attenuation Tolerance:  ①±0.6 dB ②±0.8 dB ③±1.0 dB ④±1.2 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~6.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.20
  • Attenuation Value: ①01-10 dB ②11-20 dB ③21-40 dB ④50, 60 dB
  • Attenuation Tolerance:  ①±0.6 dB ②±0.8 dB ③±1.0 dB ④±1.2 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~6.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~6.0 GHz
  • VSWR Max: 1.25
  • Attenuation Value: ①01-10 dB ②11-20 dB ③21-40 dB ④50, 60 dB
  • Attenuation Tolerance:  ①±0.6 dB ②±0.8 dB ③±1.0 dB ④±1.2 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~8.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~8.0 GHz
  • VSWR Max: 1.25
  • Attenuation Value: ①01-10 dB ②11-20 dB ③21-40 dB ④50, 60 dB
  • Attenuation Tolerance:  ①±0.8 dB ②±1.0 dB ③±1.2 dB ④±1.3 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~12.4 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~12.4 GHz
  • VSWR Max: 1.40
  • Attenuation Value: ①3 dB ②6 dB ③10 dB ④20 dB ⑤30 dB ⑥40 dB
  • Attenuation Tolerance: -1.5 dB/+2.5 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~18.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~18.0 GHz
  • VSWR Max: 1.40
  • Attenuation Value: ①3 dB ②6 dB ③10 dB ④20 dB ⑤30 dB ⑥40 dB
  • Attenuation Tolerance: -1.5 dB/+2.5 dB
  • Power: 50 W
  • Impedance: 50 Ω
  • Description: DC~4.0 GHz Coaxial Fixed Attenuator
  • Frequency Range: DC~4.0 GHz
  • VSWR Max: 1.20
  • Attenuation Value: ①01-10 dB ②11-20 dB ③25, 30, 40 dB ④50, 60 dB
  • Attenuation Tolerance:  ①±0.6 dB ②±0.8 dB ③±1.0 dB ④±1.2 dB
  • Power: 50 W
  • Impedance: 50 Ω
