RFTXX-05RA2030-N-4

by Coaxial-Fixed-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Fixed Attenuator for global customers. RFTXX-05RA2030-N-4 is a Coaxial Fixed Attenuator in Frequency Range of DC~4.0 GHz. It is made of high quality materials under a high standard, the VSWR Max of this product is 1.20, Attenuation Value is ①1-10 dB②12,13,15,20 dB③25,30,40 dB and Attenuation Tolerance is ①±0.6 dB②±0.8 dB③±1.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 5 W.

Product Specifications

Product Details

  • Part Number
    RFTXX-05RA2030-N-4
  • Description
    DC~4.0 GHz Coaxial Fixed Attenuator

General Parameters

  • Frequency Range
    DC~4.0 GHz
  • VSWR Max
    1.20
  • Attenuation Value
    ①1-10 dB②12,13,15,20 dB③25,30,40 dB
  • Attenuation Tolerance
    ①±0.6 dB②±0.8 dB③±1.0 dB
  • Power
    5 W
  • Impedance
    50 Ω
  • Connector Type
    N-J(M)/N-K(F)
  • Size
    Φ20*66 mm
  • Weight
    80 g
  • Operating Temperature
    -55~+125 °C
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
