UIYCI2536A

by Coaxial-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Isolator for global customers. UIYCI2536A is a Coaxial Isolator in Frequency Range of 4.0~8.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 20%, Insertion Loss Max is 0.30~0.50 dB and Isolation Min is 20.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 300 W.

Product Specifications

Product Details

  • Part Number
    UIYCI2536A
  • Description
    4.0 to 8.0 GHz - 300W Coaxial Isolator

General Parameters

  • Frequency Range
    4.0~8.0 GHz
  • Bandwidth Max
    20%
  • Insertion Loss Max
    0.30~0.50 dB
  • Isolation Min
    20.0~23.0 dB
  • Forward Power
    300 W
  • Reverse Power
    100 W
  • VSWR Max
    1.20~1.35
  • Impedance
    50 Ω
  • Connector Type
    N-F
  • Size
    15*22.5*13.8 mm
  • Weight
    /
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
UIYCI2536A4T45NF 4.0-4.5 0.40 20.0 1.25 300 100
UIYCI2536A45T5NF 4.5-5.0 0.35 23.0 1.20 300 100
UIYCI2536A47T51NF 4.7-5.1 0.35 23.0 1.20 300 100
UIYCI2536A48T59NF 4.8-5.9 0.50 20.0 1.25 300 100
UIYCI2536A5T6NF 5.0-6.0 0.40 20.0 1.25 300 100
UIYCI2536A57T59NF 5.7-5.9 0.30 23.0 1.20 300 100
UIYCI2536A58T65NF 5.8-6.5 0.30 23.0 1.20 300 100
UIYCI2536A65T7NF 6.5-7.0 0.40 20.0 1.25 300 100
UIYCI2536A7T8NF 7.0-8.0 0.40 20.0 1.25 300 100
