UIYDI1220A

by Drop-in-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Isolator for global customers. UIYDI1220A is a Drop in Isolator in Frequency Range of 4.0~8.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 25%, Insertion Loss Max is 0.25~0.50 dB and Isolation Min is 18.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 60 W.

Product Specifications

Product Details

  • Part Number
    UIYDI1220A
  • Description
    4.0 to 8.0 GHz Drop in Isolator

General Parameters

  • Frequency Range
    4.0~8.0 GHz
  • Bandwidth Max
    25%
  • Insertion Loss Max
    0.25~0.50 dB
  • Isolation Min
    18.0~23.0 dB
  • Forward Power
    60 W
  • Reverse Power
    5 W
  • VSWR Max
    1.20~1.30
  • Impedance
    50 Ω
  • Connector Type
    TAB
  • Size
    12×20×8 mm
  • Weight
    /
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
