Drop in Isolator

There are 69 related products in the Drop in Isolator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 18.0 to 28.0 GHz Drop in Isolator
  • Frequency Range: 26.5~40.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.50~1.70 dB
  • Isolation Min: 12.0~14.0 dB
  • Forward Power: 10 W
  • Reverse Power: 2 W
  • Description: 18.0 to 28.0 GHz Drop in Isolator
  • Frequency Range: 22.0~33.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.30~1.60 dB
  • Isolation Min: 15.0~16.0 dB
  • Forward Power: 10 W
  • Reverse Power: 2 W
  • Description: 18.0 to 28.0 GHz Drop in Isolator
  • Frequency Range: 18.0~28.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.70~0.90 dB
  • Isolation Min: 20.0 dB
  • Forward Power: 10 W
  • Reverse Power: 2 W
  • Description: 17.0 to 27.5 GHz Drop in Isolator
  • Frequency Range: 17.0~27.5 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.50~0.60 dB
  • Isolation Min: 18.0~20.0 dB
  • Forward Power: 30 W
  • Reverse Power: 5 W
  • Description: 5.0 to 25.0 GHz Drop in Isolator
  • Frequency Range: 5.0~30.0 GHz
  • Bandwidth Max: 40%
  • Insertion Loss Max: 0.30~0.60 dB
  • Isolation Min: 16.0~23.0 dB
  • Forward Power: 30 W
  • Reverse Power: 5 W
  • Description: 4.0 to 8.0 GHz Drop in Isolator
  • Frequency Range: 4.0~8.0 GHz
  • Bandwidth Max: 25%
  • Insertion Loss Max: 0.25~0.50 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 60 W
  • Reverse Power: 5 W
  • Description: 0.7 to 6.0 GHz Drop in Isolator
  • Frequency Range: 0.7~6.0 GHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.30~0.70 dB
  • Isolation Min: 15.0~23.0 dB
  • Forward Power: 100 W
  • Reverse Power: 100 W
  • Description: 0.7 to 6.0 GHz Drop in Isolator
  • Frequency Range: 0.7~6.0 GHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.30~0.70 dB
  • Isolation Min: 15.0~23.0 dB
  • Forward Power: 60 W
  • Reverse Power: 20 W
  • Description: 0.7 to 3.1 GHz Drop in Isolator
  • Reverse Power: 30 W
  • VSWR Max: 1.15~1.30
  • Impedance: 50 Ω
  • Connector Type: TAB
  • Size: 32×32×11 mm
  • Weight : /
  • Description: 0.6 to 5.0 GHz Drop in Isolator
  • Frequency Range: 0.6~5.0 GHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.25~0.50 dB
  • Isolation Min: 16.0~25.0 dB
  • Forward Power: 100 W
  • Reverse Power: 100 W
  • Description: 600 to 5000 MHz Drop in Isolator
  • Frequency Range: 600~5000 MHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.25~0.50 dB
  • Isolation Min: 16.0~25.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 400 to 3000 MHz Drop in Isolator
  • Frequency Range: 400~3000 MHz
  • Bandwidth Max: 30%
  • Insertion Loss Max: 0.25~0.70 dB
  • Isolation Min: 16.0~25.0 dB
  • Forward Power: 100 W
  • Reverse Power: 100 W
