UIYBDI1326B

by Drop-in-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Isolator for global customers. UIYBDI1326B is a Drop in Isolator in Frequency Range of 22.0~33.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 1.30~1.60 dB and Isolation Min is 15.0~16.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 10 W.

Product Specifications

Product Details

  • Part Number
    UIYBDI1326B
  • Description
    18.0 to 28.0 GHz Drop in Isolator

General Parameters

  • Frequency Range
    22.0~33.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    1.30~1.60 dB
  • Isolation Min
    15.0~16.0 dB
  • Forward Power
    10 W
  • Reverse Power
    2 W
  • VSWR Max
    1.50~1.60
  • Impedance
    50 Ω
  • Connector Type
    TAB
  • Size
    13×26×16.6 mm
  • Weight
    /
  • Operating Temperature
    -45~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
