MG0675-09

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG0675-09 is a Microstrip Isolator in Frequency Range of 10.7~12.7 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 0.50 dB, Isolation Min is 18.0 dB and VSWR Max is 1.30. The component has a good working performance and stability, it is ideal for handling a Forward Power of 10 W.

Product Specifications

Product Details

  • Part Number
    MG0675-09
  • Description
    10.7 to 12.7 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    10.7~12.7 GHz
  • Insertion Loss Max
    0.50 dB
  • Isolation Min
    18.0 dB
  • VSWR Max
    1.30
  • Forward Power
    10 W
  • Reverse Power
    10 W
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    6.0*7.5*3.0 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
MG0675-09-X/10.7-12.7GHz 10.7-12.7 0.50 18.0 1.30 10 10
