MG0506-08

by Microstrip-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Isolator for global customers. MG0506-08 is a Microstrip Isolator in Frequency Range of 17.0~22.0 GHz. It is made of high quality materials under a high standard, the Insertion Loss Max of this product is 0.60 dB, Isolation Min is 16.0 dB and VSWR Max is 1.30. The component has a good working performance and stability, it is ideal for handling a Forward Power of 5 W.

Product Specifications

Product Details

  • Part Number
    MG0506-08
  • Description
    17.0 to 22.0 GHz Microstrip Isolator

General Parameters

  • Frequency Range
    17.0~22.0 GHz
  • Insertion Loss Max
    0.60 dB
  • Isolation Min
    16.0 dB
  • VSWR Max
    1.30
  • Forward Power
    5 W
  • Reverse Power
    2 W
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    5.0*6.0*3.5 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
MG0506-08-X/17.0-22.0GHz 17.0-22.0 0.60 16.0 1.30 5 2
Request Quote
