BG4080-WR75

by Waveguide-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Waveguide Isolator for global customers. BG4080-WR75 is a Waveguide Isolator in Frequency Range of 13.7~14.7 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.25 dB and Isolation Min is 20.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of /.

Product Specifications

Product Details

  • Part Number
    BG4080-WR75
  • Description
    13.7 to 14.7 GHz Waveguide Isolator

General Parameters

  • Frequency Range
    13.7~14.7 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    0.25 dB
  • Isolation Min
    20.0 dB
  • Forward Power
    /
  • Reverse Power
    /
  • VSWR Max
    1.20
  • Impedance
    50 Ω
  • Connector Type
    WR75
  • Size
    80*40*38 mm
  • Weight
    /
  • Operating Temperature
    -40~+80 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Bandwidth Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Choose
BG4080-WR75/13.7-14.7GHz 13.7-14.7 100% 0.25 20.0 1.20
