BG6658-WR112

by Waveguide-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Waveguide Isolator for global customers. BG6658-WR112 is a Waveguide Isolator in Frequency Range of 18.0~26.5 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.20 dB and Isolation Min is 20.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100 W.

Product Specifications

Product Details

  • Part Number
    BG6658-WR112
  • Description
    18.0 to 26.5 GHz Waveguide Isolator

General Parameters

  • Frequency Range
    18.0~26.5 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    0.20 dB
  • Isolation Min
    20.0 dB
  • Forward Power
    100 W
  • Reverse Power
    20 W
  • VSWR Max
    1.20
  • Impedance
    50 Ω
  • Connector Type
    WR112
  • Size
    66.55*58.75*34.9 mm
  • Weight
    /
  • Operating Temperature
    -40~+80 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
