WH6466K

by Drop-in-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Circulator for global customers. WH6466K is a Drop in Circulator in Frequency Range of 950~2000 MHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 10%, Insertion Loss Max is 0.65~0.70 dB and Isolation Min is 16.0~17.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 150 W.

Product Specifications

Product Details

  • Part Number
    WH6466K
  • Description
    950 to 2000 MHz Drop in Circulator

General Parameters

  • Frequency Range
    950~2000 MHz
  • Bandwidth Max
    10%
  • Insertion Loss Max
    0.65~0.70 dB
  • Isolation Min
    16.0~17.0 dB
  • Power
    150 W
  • VSWR Max
    1.40
  • Impedance
    50 Ω
  • Connector Type
    /
  • Size
    64.0*66.0*26.0 mm
  • Weight
    325 g
  • Operating Temperature
    -10~+60 ℃
  • Storage Temperature
    -40~+90 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (MHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR （Max） Power （W） Choose
WH6466K-X/950-2000MHz 950-2000 0.70 16.0 1.40 150
WH6466K-X/1000-2000MHz 1000-2000 0.65 17.0 1.40 150
