SMTH-D20

by Surface-Mount-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Surface Mount Circulator for global customers. SMTH-D20 is a Surface Mount Circulator in Frequency Range of 750~2500 MHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 20%, Insertion Loss Max is 0.30~0.60 dB and Isolation Min is 17.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 60/100 W.

Product Specifications

Product Details

  • Part Number
    SMTH-D20
  • Description
    750 to 2500 MHz Surface Mount Circulator

General Parameters

  • Frequency Range
    750~2500 MHz
  • Bandwidth Max
    20%
  • Insertion Loss Max
    0.30~0.60 dB
  • Isolation Min
    17.0~23.0 dB
  • Power
    60/100 W
  • VSWR Max
    1.20~1.58
  • Impedance
    50 Ω
  • Connector Type
    SMT
  • Size
    Φ20.0*8.0 mm
  • Weight
    18 g
  • Operating Temperature
    -40~+80 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (MHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Power （CW） Choose
SMTH-D20-X/758-803MHz 758-803 0.40 20.0 1.25 60
SMTH-D20-X/900-930MHz 900-930 0.40 23.0 1.20 100
SMTH-D20-X/925-960MHz 920-960 0.40 20.0 1.25 100
SMTH-D20-X/1017-1103MHz 1017-1103 0.40 20.0 1.25 100
SMTH-D20-X/1200-1400MHz 1200-1400 0.40 20.0 1.25 100
SMTH-D20-X/1400-1500MHz 1400-1500 0.30 23.0 1.20 100
SMTH-D20-X/1600-2000MHz 1600-2000 0.60 17.0 1.35 100
SMTH-D20-X/1830-2650MHz 1830-2650 0.60 13.0 1.58 100
SMTH-D20-X/2110-2155MHz 2110-2155 0.30 23.0 1.20 60
SMTH-D20-X/2400-2500MHz 2400-2155 0.30 23.0 1.20 100
SMTH-D20-X/2500-2630MHz 2500-2630 0.40 20.0 1.25 60
