RF Solution

Surface Mount Circulator

There are 9 related products in the Surface Mount Circulator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 3000 to 6000 MHz Surface Mount Circulator
  • Frequency Range: 3000~6000 MHz
  • Bandwidth Max: 10%
  • Insertion Loss Max: 0.30~0.40 dB
  • Isolation Min: 20.0~23.0 dB
  • Power: 30 W
  • VSWR Max: 1.20~1.25
  • Description: 1400 to 6000 MHz Surface Mount Circulator
  • Frequency Range: 1400~6000 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.30~0.60 dB
  • Isolation Min: 17.0~23.0 dB
  • Power: 30 W
  • VSWR Max: 1.20~1.30
  • Description: 1400 to 6000 MHz Surface Mount Circulator
  • Connector Type : SMT
  • Size: Φ12.3*7.0 mm
  • Weight: 5 g
  • Operating Temperature: -40~+85 ℃
  • Storage Temperature: -50~+90 ℃
  • ROHS Compliant: Yes
  • Description: 1000 to 5000 MHz Surface Mount Circulator
  • Frequency Range: 1000~5000 MHz
  • Bandwidth Max: 5%
  • Insertion Loss Max: 0.25~0.40 dB
  • Isolation Min: 20.0~25.0 dB
  • Power: 60 W
  • VSWR Max: 1.15~1.25
  • Description: 1400 to 3800 MHz Surface Mount Circulator
  • Frequency Range: 800~3800 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25~0.60 dB
  • Isolation Min: 17.0~23.0 dB
  • Power: 100/500 W
  • VSWR Max: 1.20~1.30
  • Description: 800 to 5900 MHz Surface Mount Circulator
  • Frequency Range: 800~5900 MHz
  • Bandwidth Max: 15%
  • Insertion Loss Max: 0.30~0.60 dB
  • Isolation Min: 18.0~23.0 dB
  • Power: 30/50/60/100 W
  • VSWR Max: 1.25~1.30
  • Description: 750 to 2500 MHz Surface Mount Circulator
  • Frequency Range: 750~2500 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.30~0.60 dB
  • Isolation Min: 17.0~23.0 dB
  • Power: 60/100 W
  • VSWR Max: 1.20~1.58
  • Description: 400 to 1800 MHz Surface Mount Circulator
  • Frequency Range: 400~1800 MHz
  • Bandwidth Max: 10%
  • Insertion Loss Max: 0.20~0.60 dB
  • Isolation Min: 16.0~25.0 dB
  • Power: 100/200 W
  • VSWR Max: 1.15~1.40
  • Description: 300 to 1000 MHz Surface Mount Circulator
  • Frequency Range: 300~1000 MHz
  • Bandwidth Max: 10%
  • Insertion Loss Max: 0.30~0.80 dB
  • Isolation Min: 16.0~25.0 dB
  • Power: 300 W
  • VSWR Max: 1.15~1.30
