SMTH-D10

by Surface-Mount-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Surface Mount Circulator for global customers. SMTH-D10 is a Surface Mount Circulator in Frequency Range of 3000~6000 MHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 10%, Insertion Loss Max is 0.30~0.40 dB and Isolation Min is 20.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 30 W.

Product Specifications

Product Details

  • Part Number
    SMTH-D10
  • Description
    3000 to 6000 MHz Surface Mount Circulator

General Parameters

  • Frequency Range
    3000~6000 MHz
  • Bandwidth Max
    10%
  • Insertion Loss Max
    0.30~0.40 dB
  • Isolation Min
    20.0~23.0 dB
  • Power
    30 W
  • VSWR Max
    1.20~1.25
  • Impedance
    50 Ω
  • Connector Type
    SMT
  • Size
    Φ10*7.0 mm
  • Weight
    5 g
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes


Technical Documents

Specifications

Part Number Frequency Range (MHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Power （CW） Choose
SMTH-D10-X/3000-3100MHz 3000-3100 0.30 23.0 1.20 30
SMTH-D10-X/3200-3400MHz 3200-3400 0.30 20.0 1.25 30
SMTH-D10-X/3400-3600MHz 3400-3600 0.30 20.0 1.25 30
SMTH-D10-X/3800MHz 3800 0.30 23.0 1.20 30
SMTH-D10-X/5000-5300MHz 5000-5300 0.40 20.0 1.25 30
SMTH-D10-X/5300-5500MHz 5300-5500 0.30 21.0 1.20 30
SMTH-D10-X/5800-6000MHz 5800-6000 0.30 21.0 1.20 30
