MH0606-07-8-12

by Microstrip-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Circulator for global customers. MH0606-07-8-12 is a Microstrip Circulator in Frequency Range of 8.0~12.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.60 dB and Isolation Min is 16.0 dB. The component has a good working performance and stability, it is ideal for handling a Peak Power W@ Duty Cycle 25% of 40 W.

Product Specifications

Product Details

  • Part Number
    MH0606-07-8-12
  • Description
    8.0 to 12.0 GHz Microstrip Circulator

General Parameters

  • Frequency Range
    8.0~12.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    0.60 dB
  • Isolation Min
    16.0 dB
  • Peak Power W@ Duty Cycle 25%
    40 W
  • VSWR Max
    1.35
  • Impedance
    50 Ω
  • Connector Type
    Micro strip
  • Size
    6.0*6.0*3.0 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
