Microstrip Circulator

There are 19 related products in the Microstrip Circulator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 25.0 to 27.0 GHz Microstrip Circulator
  • Frequency Range: 25.0~27.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.10 dB
  • Isolation Min: 18.0 dB
  • Forward Power: 20W
  • VSWR Max: 1.30
  • Description: 24.0 to 41.5 GHz Microstrip Circulator
  • Frequency Range: 24.0~41.5 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60~1.00 dB
  • Isolation Min: 15.0~20.0 dB
  • Forward Power: 10 W
  • VSWR Max: 1.30~1.45
  • Description: 24.5 to 26.5 GHz Microstrip Circulator
  • Frequency Range: 24.5~26.5 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.50 dB
  • Isolation Min: 18.0 dB
  • Forward Power: 10 W
  • VSWR Max: 1.25
  • Description: 17.3 to 17.48 GHz Microstrip Circulator
  • Frequency Range: 17.3~17.48 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.70 dB
  • Isolation Min: 20.0 dB
  • Forward Power: 10 W
  • VSWR Max: 1.30
  • Description: 15.0 to 17.0 GHz Microstrip Circulator
  • Frequency Range: 15.0~17.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.40 dB
  • Isolation Min: 20.0 dB
  • Forward Power: 10 W
  • VSWR Max: 1.25
  • Description: 25.0 to 27.0 GHz Microstrip Circulator
  • Frequency Range: 25.0~27.0 GHz
  • Bandwidth Max: 40%
  • Insertion Loss Max: 1.10 dB
  • Isolation Min: 18.0 dB
  • Peak Power W@ Duty Cycle 25%: 2 W
  • VSWR Max: 1.30
  • Description: 11.0 to 18.0 GHz Microstrip Circulator
  • Frequency Range: 11.0~18.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.50 dB
  • Isolation Min: 20.0 dB
  • Peak Power W@ Duty Cycle 25%: 20 W
  • VSWR Max: 1.25
  • Description: 8.0 to 12.0 GHz Microstrip Circulator
  • Frequency Range: 8.0~12.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60 dB
  • Isolation Min: 16.0 dB
  • Peak Power W@ Duty Cycle 25%: 40 W
  • VSWR Max: 1.35
  • Description: 10.0 to 15.0 GHz Microstrip Circulator
  • Frequency Range: 10.0~15.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60 dB
  • Isolation Min: 16.0 dB
  • Forward Power: 2.5 W
  • VSWR Max: 1.40
  • Description: 8.0 to 11.0 GHz Microstrip Circulator
  • Frequency Range: 8.0~11.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.40~0.80 dB
  • Isolation Min: 15.0~20.0 dB
  • Forward Power: 50 W
  • VSWR Max: 1.20~1.45
  • Description: 8.0 to 11.0 GHz Microstrip Circulator
  • Frequency Range: 8.0~11.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60 dB
  • Isolation Min: 17.0 dB
  • Forward Power: 10 W
  • VSWR Max: 1.35
  • Description: 8.0 to 11.0 GHz Microstrip Circulator
  • Frequency Range: 8.0~11.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.50 dB
  • Isolation Min: 17.5 dB
  • Forward Power: 10 W
  • VSWR Max: 1.30
