RFTXXA-02MA4430-18

by Microstrip-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Attenuator for global customers. RFTXXA-02MA4430-18 is a Microstrip Attenuator in Frequency Range of DC~18.0 GHz. It is made of high quality materials under a high standard, the Attenuation Value of this product is 1~10 dB, Attenuation Tolerance is ±0.5 dB and VSWR Max is 1.30. The component has a good working performance and stability, it is ideal for handling a Rated Power of 2 W.

Product Specifications

Product Details

  • Part Number
    RFTXXA-02MA4430-18
  • Description
    DC~18.0 GHz Microstrip Attenuator

General Parameters

  • Frequency Range
    DC~18.0 GHz
  • Attenuation Value
    1~10 dB
  • Attenuation Tolerance
    ±0.5 dB
  • VSWR Max
    1.30
  • Rated Power
    2 W
  • Impedance
    50 Ω
  • Size
    4.4*3.0*0.38 mm
  • Temperature Coefficient Max
    150 ppm/℃
  • Substrate Material
    AI2O3
  • Resistance Process
    Thick Film
  • Operating Temperature
    -55~+150 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
