RFTXXA-02MA5263-12.4

by Microstrip-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Attenuator for global customers. RFTXXA-02MA5263-12.4 is a Microstrip Attenuator in Frequency Range of DC~12.4 GHz. It is made of high quality materials under a high standard, the Attenuation Value of this product is ①1-10 dB ②11-20 dB ③30 dB, Attenuation Tolerance is ①±0.5 dB ②±1.0 dB ③±1.0 dB and VSWR Max is 1.20 @10GHz, 1.25@12.4GHz. The component has a good working performance and stability, it is ideal for handling a Rated Power of 2 W.

Product Specifications

Product Details

  • Part Number
    RFTXXA-02MA5263-12.4
  • Description
    DC~12.4 GHz Microstrip Attenuator

General Parameters

  • Frequency Range
    DC~12.4 GHz
  • Attenuation Value
    ①1-10 dB ②11-20 dB ③30 dB
  • Attenuation Tolerance
    ①±0.5 dB ②±1.0 dB ③±1.0 dB
  • VSWR Max
    1.20 @10GHz, 1.25@12.4GHz
  • Rated Power
    2 W
  • Impedance
    50 Ω
  • Size
    6.35*5.2*0.5 mm
  • Temperature Coefficient Max
    150 ppm/℃
  • Substrate Material
    AI2O3
  • Resistance Process
    Thick Film
  • Operating Temperature
    -55~+150 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
