TG1220CS

by Coaxial-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Isolator for global customers. TG1220CS is a Coaxial Isolator in Frequency Range of 9.0~18.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 20%, Insertion Loss Max is 0.30~0.60 dB and Isolation Min is 18.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 30 W.

Product Specifications

Product Details

  • Part Number
    TG1220CS
  • Description
    9.0 to 18.0 GHz Coaxial Isolator

General Parameters

  • Frequency Range
    9.0~18.0 GHz
  • Bandwidth Max
    20%
  • Insertion Loss Max
    0.30~0.60 dB
  • Isolation Min
    18.0~23.0 dB
  • Forward Power
    30 W
  • Reverse Power
    5 W
  • VSWR Max
    1.20~1.35
  • Impedance
    50 Ω
  • Connector Type
    SMA-F
  • Size
    16.0*26.6*14.0 mm
  • Weight
    18 g
  • Operating Temperature
    -10~+60 ℃
  • Storage Temperature
    -50~+90 ℃
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
TG1220CS-X/9.3-9.5GHz 9.3-9.5 0.30 23.0 1.20 30 5
TG1220CS-X/9.3-9.6GHz 9.3-9.6 0.40 18.0 1.30 30 5
TG1220CS-X/10.0-13.0GHz 10.0-13.0 0.40 21.0 1.25 30 5
TG1220CS-X/10.0-15.0GHz 10.0-15.0 0.60 18.0 1.35 30 5
TG1220CS-X/10.5-12.5GHz 10.5-12.5 0.40 20.0 1.20 30 5
TG1220CS-X/10.5-15.0GHz 10.5-15.0 0.60 18.0 1.35 30 5
TG1220CS-X/10.6-12.7GHz 10.6-12.7 0.40 20.0 1.25 30 5
TG1220CS-X/10.7-12.8GHz 10.7-12.8 0.40 20.0 1.20 30 5
TG1220CS-X/10.7-13.3GHz 10.7-13.3 0.60 18.0 1.30 30 5
TG1220CS-X/10.95-12.2GHz 10.95-12.2 0.40 20.0 1.25 30 5
TG1220CS-X/11.0-14.5GHz 11.0-14.5 0.60 18.0 1.35 30 5
TG1220CS-X/12.0-18.0GHz 12.0-18.0 0.60 18.0 1.35 30 5
TG1220CS-X/12.7-14.9GHz 12.7-14.9 0.40 20.0 1.20 30 5
TG1220CS-X/13.0-15.0GHz 13.0-15.0 0.40 21.0 1.20 30 5
TG1220CS-X/13.75-15.0GHz 13.75-15.0 0.40 20.0 1.25 30 5
TG1220CS-X/14.1-15.4GHz 14.1-15.4 0.60 20.0 1.30 30 5
TG1220CS-X/14.3-14.5GHz 14.3-14.5 0.30 23.0 1.20 30 5
TG1220CS-X/14.3-14.8GHz 14.3-14.8 0.40 20.0 1.20 30 5
TG1220CS-X/14.5-16.5GHz 14.5-16.5 0.40 20.0 1.20 30 5
TG1220CS-X/14.0-18.0GHz 14.0-18.0 0.60 18.0 1.35 30 5
TG1220CS-X/15.0-17.0GHz 15.0-17.0 0.60 20.0 1.25 30 5
TG1220CS-X/15.5-16.0GHz 15.5-16.0 0.40 23.0 1.20 30 5
TG1220CS-X/16.0-18.5GHz 16.0-18.5 0.60 18.0 1.35 30 5
