THH6434AN

by Dual-Junction-Circulator
RFHB04G18GPI Image

RF Solution offer a wide selection of Dual Junction Circulator for global customers. THH6434AN is a Dual Junction Circulator in Frequency Range of 2.0-4.0GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is Full, Insertion Loss Max is 1.2 dB and Isolation Min is 36.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100 W.

Product Specifications

Product Details

  • Part Number
    THH6434AN
  • Description
    2.0 to 4.0GHz Dual Junction Coaxial Circulator

General Parameters

  • Frequency Range
    2.0-4.0GHz
  • Bandwidth Max
    Full
  • Insertion Loss Max
    1.2 dB
  • Isolation Min
    36.0 dB
  • Forward Power
    100 W
  • VSWR Max
    1.35
  • Impedance
    50 Ω
  • Connector Type
    N-F
  • Size
    64.0*34.0*21.0 mm
  • Operating Temperature
    -10~+60℃
  • Storage Temperature
    -30~+70 ℃
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (GHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR （Max） Forward Power (W) Choose
THH6434AN-X/2.0-2.6GHz 2.0-2.6 1.0 36.0 1.30 100
THH6434AN-X 2.0-2.9GHz 2.0-2.9 1.0 36.0 1.30 100
THH6434AN-X 2.0-3.0GHz 2.0-3.0 1.0 36.0 1.30 100
THH6434AN-X 2.0-3.5GHz 2.0-3.5 1.2 36.0 1.30 100
THH6434AN-X 2.0-4.0GHz 2.0-4.0 1.2 36.0 1.30 100
THH6434AN-X 2.35-4.0GHz 2.35-4.0 1.0 36.0 1.30 100
THH6434AN-X 2.4-4.0GHz 2.4-4.0 1.2 36.0 1.30 100
THH6434AN-X 2.5-3.8GHz 2.5-3.8 1.0 36.0 1.35 100
THH6434AN-X 2.5-3.5GHz 2.5-3.5 1.2 38.0 1.25 100
THH6434AN-X 2.5-4.0GHz 2.5-4.0 1.2 36.0 1.30 100
