Dual Junction Circulator

There are 27 related products in the Dual Junction Circulator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 700 to 4200 MHz Dual Junction Coaxial Circulator
  • Frequency Range: 700~4200 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 34 dB
  • Forward Power: 100 W
  • VSWR Max: 1.30
  • Description: 700 to 4200 MHz Dual Junction Coaxial Circulator
  • Frequency Range: 700~5000 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 34 dB
  • Forward Power: 200 W
  • VSWR Max: 1.30
  • Description: 400 to 1850 MHz Dual Junction Coaxial Circulator
  • Frequency Range: 400-1850 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.35
  • Description: 400 to 1850 MHz Dual Junction Coaxial Circulator
  • Frequency Range: 400-1850 MHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 300 W
  • VSWR Max: 1.35
  • Description: 3.0 to 6.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 3.0-6.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.0 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.35
  • Description: 3.0 to 6.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 3.0-6.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.0 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.35
  • Description: 2.0 to 4.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 2.0-4.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.35
  • Description: 2.0 to 4.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 2.0-4.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.35
  • Description: 1.0 to 2.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 1.0-2.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.4 dB
  • Isolation Min: 32.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.40
  • Description: 1.0 to 2.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 1.0-2.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.3 dB
  • Isolation Min: 34.0 dB
  • Forward Power: 100 W
  • VSWR Max: 1.40
  • Description: 4.0 to 8.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 4.0-8.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.2 dB
  • Isolation Min: 34.0 dB
  • Forward Power: 50 W
  • VSWR Max: 1.35
  • Description: 4.0 to 8.0GHz Dual Junction Coaxial Circulator
  • Frequency Range: 4.0-8.0GHz
  • Bandwidth Max: Full
  • Insertion Loss Max: 1.6 dB
  • Isolation Min: 36.0 dB
  • Forward Power: 50 W
  • VSWR Max: 1.30
