UIYDI1318A

by Drop-in-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Drop in Isolator for global customers. UIYDI1318A is a Drop in Isolator in Frequency Range of 17.0~27.5 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 20%, Insertion Loss Max is 0.50~0.60 dB and Isolation Min is 18.0~20.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 30 W.

Product Specifications

Product Details

  • Part Number
    UIYDI1318A
  • Description
    17.0 to 27.5 GHz Drop in Isolator

General Parameters

  • Frequency Range
    17.0~27.5 GHz
  • Bandwidth Max
    20%
  • Insertion Loss Max
    0.50~0.60 dB
  • Isolation Min
    18.0~20.0 dB
  • Forward Power
    30 W
  • Reverse Power
    5 W
  • VSWR Max
    1.25~1.30
  • Impedance
    50 Ω
  • Connector Type
    TAB
  • Size
    13×18×13.8 mm
  • Weight
    /
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
