RF Solution offer a wide selection of Drop in Circulator for global customers. WH2528C is a Drop in Circulator in Frequency Range of 3.0~6.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.40~0.50 dB and Isolation Min is 18.0~20.0 dB. The component has a good working performance and stability, it is ideal for handling a Power of 150 W.
| Part Number | Frequency Range (GHz) | Insertion Loss Max (dB) | Isolation Min (dB) | VSWR （Max） | Power （W） | Choose |
|---|---|---|---|---|---|---|
| WH2528C-X/3000-4000MHz | 3.0-4.0 | 0.40 | 20.0 | 1.20 | 150 | |
| WH2528C-X/3000-5000MHz | 3.0-5.0 | 0.50 | 18.0 | 1.25 | 150 | |
| WH2528C-X/3000-6000MHz | 3.0-6.0 | 0.50 | 18.0 | 1.30 | 150 | |
| WH2528C-X/4000-5000MHz | 4.0-5.0 | 0.40 | 20.0 | 1.25 | 150 | |
| WH2528C-X/4000-6000MHz | 4.0-6.0 | 0.45 | 20.0 | 1.25 | 150 | |
| WH2528C-X/5000-6000MHz | 5.0-6.0 | 0.40 | 18.0 | 1.30 | 150 |
