RFTXX-05MA5263-12.4

by Microstrip-Attenuator
RFHB04G18GPI Image

RF Solution offer a wide selection of Microstrip Attenuator for global customers. RFTXX-05MA5263-12.4 is a Microstrip Attenuator in Frequency Range of DC~12.4 GHz. It is made of high quality materials under a high standard, the Attenuation Value of this product is ①1-10 dB ②11-20 dB ③21-30 dB, Attenuation Tolerance is ①±0.6 dB ②±0.7 dB ③± 1.0 dB and VSWR Max is 1.25 type 1.3. The component has a good working performance and stability, it is ideal for handling a Rated Power of 5 W.

Product Specifications

Product Details

  • Part Number
    RFTXX-05MA5263-12.4
  • Description
    DC~12.4 GHz Microstrip Attenuator

General Parameters

  • Frequency Range
    DC~12.4 GHz
  • Attenuation Value
    ①1-10 dB ②11-20 dB ③21-30 dB
  • Attenuation Tolerance
    ①±0.6 dB ②±0.7 dB ③± 1.0 dB
  • VSWR Max
    1.25 type 1.3
  • Rated Power
    5 W
  • Impedance
    50 Ω
  • Size
    6.35*5.2*0.5 mm
  • Temperature Coefficient Max
    150 ppm/℃
  • Substrate Material
    BeO
  • Resistance Process
    Thick Film
  • Operating Temperature
    -55~+150 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
