UIYCI5656A

by Coaxial-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Coaxial Isolator for global customers. UIYCI5656A is a Coaxial Isolator in Frequency Range of 130~900 MHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 40%, Insertion Loss Max is 0.30~0.60 dB and Isolation Min is 15.0~23.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100/500 W.

Product Specifications

Product Details

  • Part Number
    UIYCI5656A
  • Description
    70 to 130 MHz Coaxial Isolator

General Parameters

  • Frequency Range
    130~900 MHz
  • Bandwidth Max
    40%
  • Insertion Loss Max
    0.30~0.60 dB
  • Isolation Min
    15.0~23.0 dB
  • Forward Power
    100/500 W
  • Reverse Power
    30 W
  • VSWR Max
    1.20~1.50
  • Impedance
    50 Ω
  • Connector Type
    N-F/SMA-F
  • Size
    56*56*15 mm
  • Weight
    /
  • Operating Temperature
    -30~+70 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes

Technical Documents

Specifications

Part Number Frequency Range (MHz) Insertion Loss Max (dB) Isolation Min (dB) VSWR Max Forward Power (W) Reverse Power (W) Choose
UIYCI5656A136T150NF 136-150 0.50 18.0 1.30 300 30
UIYCI5656A150T155SF 150-155 0.50 20.0 1.25 100 30
UIYCI5656A150T170SF 150-170 0.60 18.0 1.30 100 30
UIYCI5656A168T171NF 168-171 0.40 23.0 1.20 300 30
UIYCI5656A170T200SF 170-200 0.70 18.0 1.30 100 30
UIYCI5656A180T220SF 180-220 0.50 18.0 1.30 100 30
UIYCI5656A192T232NF 192-232 0.40 20.0 1.25 300 30
UIYCI5656A1975T2075SMTSF 197.5-207.5 0.40 23.0 1.20 100 30
UIYCI5656A200T250SF 200-250 0.60 20.0 1.25 100 30
UIYCI5656A230T250NF 230-250 0.30 23.0 1.20 300 30
UIYCI5656A250T300SF 250-300 0.40 20.0 1.25 100 30
UIYCI5656A400T600SF 400-600 0.60 15.0 1.50 100 30
UIYCI5656A500T750SF 500-750 0.50 16.0 1.40 100 30
UIYCI5656A600T900SF 600-900 0.50 17.0 1.35 100 30
